Solis 60kW S5 3 Phase 6x MPPT - DC | IP66
Solis 60kW S5 3 Phase 6x MPPT - DC
#1: SOL-S5-GC60K-DC
#4: S5-GC60K-DC-PID
Solis 60kW 3-Phase Grid-Tie Inverter – High Efficiency Commercial Solar Solution
The Solis 60kW Three-Phase Inverter is a powerful and efficient solution for commercial and utility-scale solar PV systems. Built with advanced grid-tie technology, intelligent monitoring, and enhanced safety features, this inverter delivers maximum energy yield and long-lasting reliability.
⚡ Key Features
-
🔋 Rated Output: 60,000W (66kW max AC output)
-
🌞 High Efficiency: Max. efficiency of 98.7% (Euro efficiency 98.4%)
-
🌐 6 MPPT Design with 2 DC inputs per MPPT to minimise string mismatch
-
⚡ Wide Voltage Range: 195V start-up, up to 1100V PV input
-
🛡️ Safety First:
-
Type II surge protection (DC & AC)
-
AFCI (arc-fault circuit protection)
-
DC reverse polarity protection
-
Integrated DC switch for emergency shut-down & safe maintenance
-
-
🏗️ Durable Build: IP66 rating & C5 anti-corrosion level for tough environments
-
📡 Smart Monitoring: Intelligent I-V curve diagnosis with PLC/GPRS/WiFi options
-
✅ Certified: SA: NRS-097-2-1 compliant
-
📅 Warranty: 5 years standard
📊 Technical Specifications
| Specification | Details |
|---|---|
| Rated Power | 60,000 W |
| Maximum AC Output (5 min) | 66,000 W |
| Surge AC Power (1 sec) | 66,000 W |
| Max DC Power | 90,000 W |
| Phases | 3 |
| Min / Max PPT Voltage | 195 V / 1000 V |
| Startup / Shutdown Voltage | 195 V / 180 V |
| Max Input Voltage | 1100 V |
| Max DC Current | 192 A |
| Max DC Inputs | 12 (2 per MPPT) |
| MPPT Quantity | 6 |
| Euro Efficiency | 98.4 % |
| Max Efficiency | 98.7 % |
| Integrated DC Switch | Yes |
| Connectors | 24 x MC4 |
| Weight | 54.5 kg |
| Warranty | 5 Years |
💡 Why Choose the Solis 60kW 3-Phase Inverter?
-
Perfect for commercial & industrial solar PV projects
-
High efficiency for maximum return on investment
-
Advanced safety & protection systems
-
Seamless integration with SolisCloud remote monitoring platform
-
Reliable, durable, and easy to install
🔑 Upgrade your large-scale solar installation with the Solis 60kW Grid-Tie Inverter – delivering efficiency, durability, and intelligent monitoring for commercial energy solutions.
