Victron EasySolar-II 48V 3000VA MPPT 250/70 GX
Victron EasySolar-II 48V 3000VA MPPT 250/70 GX
#17: Victron EasySolar-II 48/3000/35-32 MPPT 250/70 GX (48V 3000VA)
To view our full range of Victron products visit our main Victron page here
Victron EasySolar All-in-One Solar Power Solution
Overview
The Victron EasySolar is an integrated solar power system combining a MPPT solar charge controller, an inverter/charger, and AC distribution in a single compact enclosure. Designed for ease of installation, it reduces wiring complexity and saves both time and space. The system is ideal for off-grid solar setups or backup power applications.
Key Features
-
All-in-one design: MPPT controller, inverter/charger, and AC distribution in one unit
-
Easy installation: Minimises wiring and setup time
-
PowerAssist technology: Prevents utility or generator overload by supplementing with inverter power
-
Dual MPPT: Two BlueSolar MPPT controllers for maximum energy harvest
-
24V model: BlueSolar MPPT 100/50, supporting up to 3 PV strings
-
48V model: BlueSolar MPPT 150/35 for larger PV arrays
-
-
AC distribution: Includes RCD (30mA/16A) and four protected AC outputs (two 10A, two 16A)
-
Flexible battery charging: Charge from PV, utility grid, or genset
Inverter Specifications
-
Input Voltage Range: 19–33V (24V model)
-
Continuous Output Power: 3000VA / 2500W
-
Peak Power: 6000W
-
Maximum Efficiency: 94%
-
Zero-Load Power Consumption: 15–16W
Charger Specifications
-
AC Input: 187–265VAC, 45–65Hz
-
Charger Current: 70A (24V) / 35A (48V)
Solar MPPT Controller Specifications
-
Max PV Open Circuit Voltage: 100V (24V model)
-
Max PV Power: 2 × 1400W (24V)
-
Max Output Current: 2 × 50A
Enclosure Details
-
Weight: 21 kg
-
Dimensions (H × W × D): 362 × 374 × 218 mm
The Victron EasySolar offers a compact, efficient, and versatile solution for off-grid solar installations, combining high-efficiency MPPT charge control, robust inverter/charger performance, and safe AC distribution in one convenient unit.
