SolarEdge 3kw Single Phase HD Wave on grid solar Inverter

#2: SE-3000H-APP Inverters - Main Units
#4: SE3000H-RW000BEN4

SolarEdge 3kw Data Sheet

SolarEdge 3kw Manual

SolarEdge 3kw Warranty

SolarEdge 3kw G100 Certificate

SolarEdge Single Phase HD-Wave Inverter – High Efficiency & Smart Solar

The SolarEdge Single Phase Inverter with HD-Wave technology is a revolutionary solution for residential solar installations. Winner of the 2016 Intersolar Award and the 2018 Edison Award, this inverter works seamlessly with SolarEdge power optimizers to maximise energy production, reduce costs, and improve system reliability.

With a record-breaking 99% efficiency and a lightweight, compact design, the SolarEdge inverter delivers outstanding performance and ROI for homeowners and businesses.

---

Key Features & Benefits

✔ Innovative HD-Wave Technology

• Smaller and lighter than traditional inverters without compromising performance.

• Achieves up to 99% efficiency, maximising energy production.

• Simple and reliable design with DC-to-AC inversion only.

✔ Smart Commissioning with SetApp

• No built-in display required – configure and monitor the inverter via the SetApp mobile application.

• Easy smartphone-based commissioning reduces installation time.

✔ Reliable & Durable

• Standard 12-year warranty, extendable to 20 or 25 years for long-term peace of mind.

• Integrated DC switch for safe operation.

• Transformerless design for lighter, simpler, and cost-effective installation.

---

Technical Specifications

• Rated Power: 3,000 W

• Phases: 1

• Max Input Voltage: 480 V

• Max DC Power: 6,000 W

• Max AC Power (5 min): 3,000 W

• Surge AC Power (1 sec): 3,000 W

• Max DC Current: 9 A

• Max DC Inputs: 1

• DC Fuses: None

• Connector Type: MC4

• Included Connectors: 2

• Euro Efficiency: 98.8%

• Transformer: None

• MPPT Quantity: 0

• Weight: 9.5 kg

• Warranty: 12 years (extendable to 20 or 25 years)

---

Why Choose SolarEdge HD-Wave Inverters?

• Maximise energy production and ROI with innovative HD-Wave technology.

• Simplified installation and commissioning using SetApp.

• Compatible with SolarEdge optimizers for safer and more reliable PV systems.

---

⚡ Upgrade your residential solar system with the SolarEdge Single Phase HD-Wave Inverter – compact, efficient, and smartly engineered for high performance.
